    Resistant To Centrifugal Forces Neodymium Magnet With Nickel Zn Ni-cu-ni Coating Strong Magnet

    Resistant to Centrifugal Forces Neodymium Magnet with Nickel Zn Ni-cu-ni Coating strong magnet

    Product Description:

    The NdFeB Magnet is customizable in size according to your needs. It can withstand centrifugal forces of no less than 110,000 RPM, making it an ideal choice for high-speed applications. This feature ensures that the magnet will remain in place even in the most challenging environments.

    The manufacturing process of the NdFeB Magnet is through sintering. This process involves the use of heat and pressure to compact the raw materials into the desired shape. The result is a magnet that has a high degree of accuracy and consistency.

    The NdFeB Magnet has a tolerance of +/- 0.02 mm, which means that it has a high level of precision and consistency in its size. This feature makes it an ideal choice for applications that require high accuracy and repeatability.

    Our NdFeB Magnet is available in a wide range of grades, including N35-N55, 42M-54M, 40H-54H, 30SH-52SH, 28UH-48UH, 28EH-38EH, and 28AH-40AH. These grades have different magnetic properties that suit different applications. Whether you need a magnet with high resistance to demagnetization, high maximum energy product, or high coercivity, we have the right grade for you.

    In summary, the NdFeB Magnet is a powerful magnet that is ideal for various applications. Its customizable size, high tensile strength, sintering process, high tolerance, and a wide range of grades make it a top choice in the market today. Get your NdFeB Magnet today and enjoy its exceptional magnetic properties.

    Features:

    • Product Name: NdFeB Magnet
    • Magnetization Methods:
      • Axial Single-Pole
      • Radial Multipolar
      • Radial Radiate Ring
    • Tolerance: +/- 0.02 Mm
    • Grade Available: N35-N55 42M-54M 40H-54H 30SH-52SH 28UH-48UH 28EH-38EH 28AH-40AH
    • Coating: Nickel Zn Ni-cu-ni
    • Size: Custom

    Neodymium Permanent Magnet

    NdFeB Magnet

    Applications:

    With ISO9001 certification, you can trust the quality of this NdFeB magnet. The magnet comes in a custom size and is available in a wide variety of grades, including N35-N55, 42M-54M, 40H-54H, 30SH-52SH, 28UH-48UH, 28EH-38EH, and 28AH-40AH.

    The JN-ND-38 NdFeB magnet has a tensile strength that resists centrifugal forces of no less than 110,000 RPM, making it perfect for use in applications that require high speeds. The magnetization methods available include axial single-pole, radial multipolar, and radial radiate ring, giving you the flexibility to use the magnet in a variety of ways.

    The NdFeB magnet is widely used in various industries, including electronics, automotive, medical, and aerospace. It is commonly used in motors, speakers, sensors, and other devices that require a strong magnetic field.

    The JN-ND-38 NdFeB magnet is available for delivery in 21 days and payment can be made through L/C or T/T. The supply ability of this magnet is 1,000K PCS/month, making it easy to obtain in large quantities.

    The magnet can be packaged for delivery by sea pallet, air carton, or express packaging. Whether you're a small business owner or a large corporation, the JN-ND-38 NdFeB magnet is an excellent choice for your magnetic needs.

    Customization:

    Brand Name: JN

    Model Number: JN-ND-38

    Place of Origin: CHINA

    Certification: ISO9001

    Minimum Order Quantity: 1000PCS

    Price: Negotiable

    Packaging Details: By Sea Pallet /By Air Carton / By Express Packaging

    Delivery Time: 21 Days

    Payment Terms: L/C,T/T

    Supply Ability: 1 000K PCS/Month

    Magnetization Methods: Axial Single-Pole /Radial Multipolar /Radial Radiate Ring

    Application: High-speed Motor Sewing Machine High-speed Hair Dryer High-efficiency Vacuum Cleaner

    Tolerance: +/- 0.02 Mm

    Raw Material: NdFeB Rare Earth Materials

    Grade Available: N35-N55 42M-54M 40H-54H 30SH-52SH 28UH-48UH 28EH-38EH 28AH-40AH

    Our NdFeB magnets are made of super strong magnetic material, also known as Neodymium Rare Earth Magnet, which is ideal for high-speed motors, sewing machines, hair dryers, and vacuum cleaners. Contact us to discuss your specific needs and we can customize the magnetization methods, packaging, and more.

    Magnetic Properties
    GradeRemanenceIntrinsic CoercivityMax Magnetic Energy ProductTemperature CoefficientMax Working TempertureDensity
    BrHcj(BH)maxα Brβ HcjTwρ
    TkGskA/mkOeKJ/m3MGOe%/℃%/℃g/cm2
    N55≥1.45≥14.5≥955≥12406-43751-55-0.12-0.880≥7.5
    N54≥1.44≥14.4≥955≥12398-43750-55-0.12-0.880≥7.5
    N521.42-1.4414.2-14.4≥955≥12390-42249-53-0.12-0.880≥7.5
    N501.4-1.4214-14.2≥955≥12374-40647-51-0.12-0.880≥7.5
    N481.37-1.413.7-14≥955≥12366-39046-49-0.12-0.880≥7.5
    N451.32-1.3713.2-13.7≥955≥12342-36643-46-0.12-0.880≥7.5
    54M≥1.44≥14.4≥1114≥14398-42250-53-0.12-0.8100≥7.5
    52M1.42-1.4414.2-14.4≥1114≥14390-42249-53-0.12-0.8100≥7.5
    50M1.4-1.4214-14.2≥1114≥14374-40647-51-0.12-0.8100≥7.5
    48M1.37-1.413.7-14≥1114≥14366-39046-49-0.12-0.8100≥7.5
    45M1.32-1.3713.2-13.7≥1114≥14342-36643-46-0.12-0.8100≥7.5
    42M1.28-1.3212.8-13.2≥1114≥14318-34240-43-0.12-0.8100≥7.5
    54H≥1.44≥14.4≥1353≥17398-42250-53-0.12-0.7120≥7.5
    52H1.42-1.4414.2-14.4≥1353≥17390-42249-53-0.12-0.7120≥7.5
    50H1.4-1.4214-14.2≥1353≥17374-40647-51-0.12-0.7120≥7.5
    48H1.37-1.413.7-14≥1353≥17366-39046-49-0.12-0.7120≥7.5
    45H1.32-1.3713.2-13.7≥1353≥17342-36643-46-0.12-0.7120≥7.5
    42H1.28-1.3212.8-13.2≥1353≥17318-34240-43-0.12-0.7120≥7.5
    40H1.26-1.2812.6-12.8≥1353≥17302-32638-41-0.12-0.7120≥7.5
    52SH1.42-1.4414.2-14.4≥1592≥20390-42249-53-0.12-0.6150≥7.5
    50SH1.4-1.4214-14.2≥1592≥20374-40647-51-0.12-0.6150≥7.5
    48SH1.37-1.413.7-14≥1592≥20366-39046-49-0.12-0.6150≥7.5
    45SH1.32-1.3713.2-13.7≥1592≥20342-36643-46-0.12-0.6150≥7.5
    42SH1.28-1.3212.8-13.2≥1592≥20318-34240-43-0.12-0.6150≥7.5
    40SH1.26-1.2812.6-12.8≥1592≥20302-32638-41-0.12-0.6150≥7.5
    38SH1.22-1.2612.2-12.6≥1592≥20287-31036-39-0.12-0.6150≥7.5
    35SH1.17-1.2211.7-12.2≥1592≥20263-28733-36-0.12-0.6150≥7.5
    33SH1.13-1.1711.3-11.7≥1592≥20247-27131-34-0.12-0.6150≥7.5
    30SH1.08-1.1310.8-11.3≥1592≥20223-25428-32-0.12-0.6150≥7.5
    48UH1.36-1.413.6-14≥1990≥25366-39046-49-0.12-0.6180≥7.5
    45UH1.32-1.3713.2-13.7≥1990≥25342-36643-46-0.12-0.6180≥7.5
    42UH1.28-1.3212.8-13.2≥1990≥25318-34240-43-0.12-0.6180≥7.5
    40UH1.26-1.2812.6-12.8≥1990≥25302-32638-41-0.12-0.6180≥7.5
    38UH1.22-1.2612.2-12.6≥1990≥25287-31036-39-0.12-0.6180≥7.5
    35UH1.17-1.2211.7-12.2≥1990≥25263-28733-36-0.12-0.6180≥7.5
    33UH1.13-1.1711.3-11.7≥1990≥25247-27131-34-0.12-0.6180≥7.5
    30UH1.08-1.1310.8-11.3≥1990≥25223-25528-32-0.12-0.51180≥7.5
    28UH1.02-1.0810.2-10.8≥1990≥25207-23126-29-0.12-0.51180≥7.5
    42EH1.28-1.3212.8-13.2≥2388≥30318-34240-43-0.12-0.5200≥7.5
    40EH1.25-1.2812.5-12.8≥2388≥30302-32638-41-0.12-0.5200≥7.5
    38EH1.22-1.2612.2-12.6≥2388≥30287-31036-39-0.12-0.5200≥7.5
    35EH1.17-1.2211.7-12.2≥2388≥30263-28733-36-0.12-0.5200≥7.5
    33EH1.13-1.1711.3-11.7≥2388≥30247-27131-34-0.12-0.5200≥7.5
    30EH1.08-1.1310.8-11.3≥2388≥30223-25528-32-0.12-0.51200≥7.5
    28EH1.02-1.0810.2-10.8≥2388≥30207-23126-29-0.12-0.51200≥7.5
    40AH1.25-1.2812.5-12.8≥2786≥35302-32638-41-0.12-0.51220≥7.5
    38AH1.22-1.2612.2-12.6≥2786≥35287-31036-39-0.12-0.51220≥7.5
    35AH1.17-1.2211.7-12.2≥2786≥35263-28733-36-0.12-0.51220≥7.5
    33AH1.13-1.1711.3-11.7≥2786≥35247-27131-34-0.12-0.51220≥7.5
    30AH1.08-1.1310.8-11.3≥2786≥35223-25528-32-0.12-0.51220≥7.5
    28AH1.02-1.0810.2-10.8≥2786≥35199-23125-29-0.12-0.51220≥7.5
