Three Phase Permanent Magnet Synchronous Motor For Electric Wrenches 1.1-11KW

Ask Lasest Price
Brand Name :	HC
Model Number :	JN-HCP-4
Certification :	ISO9001 CCC CE
Price :	Negotiable
Delivery Time :	25 Days
Payment Terms :	L/C,T/T
Supply Ability :	30K PCS/Month

Add to Cart

Product Details
Company Profile

Three Phase Permanent Magnet Synchronous Motor For Electric Wrenches 1.1-11KW

Three Phase Permanent Magnet Synchronous Motor for Electric Wrenches 1.1-11KW

Product Description:

Permanent Magnet Synchronous Motor

Product Overview

A Permanent Magnet Synchronous Motor, also known as a Blushless AC Synchronous Motor or a Synchronous Permanent Magnet Motor, is a type of electric motor that uses permanent magnets in its rotor to create a magnetic field. It is an advanced and efficient motor that is widely used in various industries and applications.

The motor is designed to work with a variable frequency drive (VFD) for speed adjustment, making it suitable for different operating conditions. It has a working system of S1, which means it can continuously operate at a constant load.

The Permanent Magnet Synchronous Motor is characterized by its use of permanent magnets in the rotor, which eliminates the need for a separate excitation system, resulting in energy-saving and efficient performance. It also has a high power density, meaning it can deliver a high output power in a compact size.

With its permanent magnets, the motor is able to produce a high torque output, making it suitable for applications that require high starting torque or heavy load conditions. It also operates with low vibration and noise levels, providing a comfortable and quiet working environment.

The motor is rated for an output power of 1.1 to 11 kilowatts and has a rated speed range of 750 to 3000 revolutions per minute (r/min). This wide speed range allows for flexible and precise control of the motor's speed, making it suitable for various applications.

In addition, the Permanent Magnet Synchronous Motor is known for its reliable performance and long operating life. It requires minimal maintenance, thanks to its simple and robust design, making it a cost-effective option for many industries.

Key Features

Blushless AC Synchronous Motor
Synchronous Permanent Magnet Motor
Permanent Magnet AC Motor
Energy-saving and Efficient
High Power Density
High Torque
Low Vibration and Noise
Reliable Performance
Wide Speed Range
Easy Maintenance

Features:

Product Name: Permanent Magnet Synchronous Motor
Rated speed: 750r~3000r
Type: Permanent Magnet
Rated voltage: 380V Or Made To Order
Category: Electric Wrenches
Dimensions: As Customers’ Requirements
Synchronous Permanent Magnet Motor
Blushless AC Synchronous Motor
High Efficiency
Low Noise
Compact Design

Technical Parameters:

Product Name:	Permanent Magnet Synchronous Motor
Phase:	Three-phase
Insulation Level:	F
Rated Output:	1.1~11KW
Rated Speed:	750r~3000r
Main Parts:	Imported
Protection Grade:	IP54/IP55
Type:	Permanent Magnet
Rated Voltage:	380V Or Made To Order.
Speed Adjust:	By VFD
Cooling Type:	IC01

Key Features:	External Rotor Motor, PMSM, Permanent Magnet AC Motor, High Efficiency

Motor model	Rated power	Rated current	Rated speed	Efficiency	Power Factor	Stall torque	Stall current	Pull-out torque	Weight
Motor model	KW	380V/A	r/min	ŋ%	COSØ	N.M	A	N.M	kg
HCP90S-2	1.5	2.8	3000	88	≥0.95	3.1	7	2	23
HCP90L-2	2.2	4	3000	89.7	≥0.95	3.1	7	2	26.5
HCP100L-2	3	5.4	3000	89.7	≥0.95	3.1	7.5	2	34
HCP112M-2	4	7.2	3000	90.7	≥0.95	3.1	7.5	2	41
HCP132S-2	5.5	9.8	3000	92	≥0.95	3.1	7.5	2	60
HCP132M-2	7.5	13.2	3000	92.5	≥0.95	3.1	7.5	2	63
HCP160M-2	11	19.3	3000	93.5	≥0.95	3	7.5	2	109
HCP160L-2	15	26	3000	93.8	≥0.95	3	7.5	2	119
HCP180M-2	22	38	3000	94.7	≥0.95	3	7.5	1.8	173
HCP180M-2	30	51.3	3000	95	≥0.95	3	7.5	1.8	186
HCP180L-2	37	63.8	3000	95.3	≥0.95	3	7.5	1.8	218
HCP200L-2	30	51.3	3000	95	≥0.95	3	7.5	1.8	225
HCP200L-2	37	63.5	3000	95.2	≥0.95	3	7.5	1.8	245
HCP200L-2	45	76.5	3000	95.6	≥0.95	3	7.5	1.8	265
HCP225S-2	45	76.5	3000	95.6	≥0.95	3	7.5	1.8	306
HCP225M-2	55	94	3000	95.8	≥0.95	3	7.5	1.8	340
HCP250M-2	55	94	3000	95.8	≥0.95	3	7.5	1.8	385
HCP280S-2	75	128	3000	96	≥0.95	3	7.5	1.8	518
HCP280M-2	90	153.3	3000	96.1	≥0.95	3	7.5	1.8	550
HCP315S-2	110	187.3	3000	96.2	≥0.95	2.9	7.1	1.8	932
HCP315M-2	132	225	3000	96.2	≥0.95	2.9	7.1	1.6	982
HCP315L-2	160	272	3000	96.5	≥0.95	2.9	7.1	1.6	1100
HCP315L-2	180	306	3000	96.5	≥0.95	2.9	7.1	1.6	1180
HCP315L-2	200	340	3000	96.6	≥0.95	2.9	7.1	1.6	1280
HCP355M-2	250	426	3000	96.8	≥0.95	2.9	7.1	1.6	1720
HCP355L-2	315	533	3000	96.8	≥0.95	2.9	7.1	1.6	1980

Motor model	Rated power	Rated current	Rated speed	Efficiency	Power Factor	Stall torque	Stall current	Pull-out torque	Weight
Motor model	KW	380V/A	r/min	ŋ%	COSØ	N.M	A	N.M	kg
HCP90S-4	1.1	2.05	1500	88	≥0.95	3.1	7	2	23
HCP90L-4	1.5	2.78	1500	88.5	≥0.95	3.1	7	2	27.5
HCP100L-4	2.2	3.98	1500	90.2	≥0.95	3.1	7.0	2	35
HCP100L-4	3.0	5.4	1500	90.7	≥0.95	3.1	7.0	2	40
HCP112M-4	4.0	7.2	1500	91	≥0.95	3.1	7.0	2	45
HCP132S-4	5.5	9.7	1500	92.6	≥0.95	3.1	7.0	2	63
HCP132M-4	7.5	13.2	1500	93.0	≥0.95	3	7.0	2	75
HCP160M-4	11.0	19.3	1500	94.0	≥0.95	3	7.5	2	115
HCP160L-4	15.0	26	1500	94.3	≥0.95	3	7.5	1.8	135
HCP180M-4	18.5	32	1500	95	≥0.95	3	7.5	1.8	172
HCP180L-4	22.0	38	1500	95.2	≥0.95	3	7.5	1.8	185
HCP200L-4	30.0	51.6	1500	95	≥0.95	3	7.2	1.8	235
HCP225S-4	37.0	63.5	1500	95.8	≥0.95	3	7.2	1.8	300
HCP225M-4	45.0	77	1500	96.1	≥0.95	3	7.2	1.8	330
HCP250M-4	55.0	94	1500	96.3	≥0.95	3	7.2	1.8	410
HCP250M-4	75.0	128	1500	96.5	≥0.95	3	7.2	1.8	438
HCP280S-4	75.0	128	1500	96.5	≥0.95	3	7.2	1.8	518
HCP280M-4	90.0	153	1500	97	≥0.95	3	7.2	1.8	608
HCP280M-4	110.0	187.2	1500	96.7	≥0.95	3	7.2	1.8	650
HCP280M-4	132.0	223	1500	96.8	≥0.95	2.9	7.2	1.8	370
HCP315S-4	110.0	187.2	1500	96.7	≥0.95	2.9	6.9	1.6	935
HCP315L-4	160.0	272	1500	96.8	≥0.95	2.9	6.9	1.6	1100
HCP315L-4	200.0	340	1500	96.9	≥0.95	2.9	6.9	1.6	1350
HCP355M-4	250.0	423	1500	97.0	≥0.95	2.9	6.9	1.6	1900
HCP355L-4	355.0	602	1500	97.1	≥0.95	2.9	6.9	1.6	2100
HCP355L-4	400.0	678	1500	97.1	≥0.95	2.9	6.9	1.6	2300

Motor model	Rated power	Rated current	Rated speed	Efficiency	Power Factor	Stall torque	Stall current	Pull-out torque	Weight
Motor model	KW	380V/A	r/min	ŋ%	COSØ	N.M	A	N.M	kg
HCP90S-6	0.75	1.4	1000	87.2	≥0.95	3.1	5.5	2	24
HCP90L-6	1.1	2.03	1000	88.7	≥0.95	3.1	5.5	2	26
HCP100L-6	1.5	2.73	1000	89.8	≥0.95	3.1	6.5	2	35
HCP112M-6	2.2	3.97	1000	91	≥0.95	3.1	6.5	2	40
HCP132S-6	3	5.37	1000	92	≥0.95	3.1	6.5	2	60
HCP132M-6	4	7.08	1000	92.8	≥0.95	3.1	6.5	2	75
HCP132M-6	5.5	9.68	1000	93.5	≥0.95	3.1	6.5	2	78
HCP160M-6	7.5	13	1000	94.2	≥0.95	3	6.5	2	110
HCP160L-6	11	19	1000	94.7	≥0.95	3	6.5	2	135
HCP180L-6	15	25.8	1000	95.1	≥0.95	3	7	2	175
HCP200L-6	18.5	31.8	1000	95.5	≥0.95	3	7	1.8	220
HCP200L-6	22	37.8	1000	95.8	≥0.95	3	7	1.8	230
HCP225M-6	30	51.3	1000	96.2	≥0.95	2.9	7	1.8	280
HCP250M-6	37	63.2	1000	96.3	≥0.95	2.9	7	1.8	380
HCP280S-6	45	76.8	1000	96.4	≥0.95	2.9	7	1.8	480
HCP280M-6	55	93.8	1000	96.5	≥0.95	2.9	7	1.8	550
HCP315S-6	75	128	1000	96.5	≥0.95	2.8	6.7	1.6	870
HCP315M-6	90	153	1000	96.5	≥0.95	2.8	6.7	1.6	950
HCP315L-6	110	187	1000	96.6	≥0.95	2.8	6.7	1.6	1130
HCP315L-6	132	223	1000	96.6	≥0.95	2.8	6.7	1.6	1190
HCP355M-6	160	263	1000	96.6	≥0.95	2.8	6.7	1.6	1720
HCP355M-6	200	340	1000	96.7	≥0.95	2.8	6.7	1.6	1900
HCP355L-6	250	425	1000	96.7	≥0.95	2.8	6.7	1.6	2000
HCP355L-6	315	536	1000	96.7	≥0.95	2.8	6.7	1.6	2200
HCP355L-6	375	637	1000	96.7	≥0.95	2.8	6.7	1.6	2300
HCP355L-6	400	680	1000	96.7	≥0.95	2.8	6.7	1.6	2450

Motor model	Rated power	Rated current	Rated speed	Efficiency	Power Factor	Stall torque	Stall current	Pull-out torque	Weight
Motor model	KW	380V/A	r/min	ŋ%	COSØ	N.M	A	N.M	kg
HCP112M-8	1.5	2.74	750	90	≥0.95	3.1	6	2	43
HCP132S-8	2.2	4	750	90.4	≥0.95	3.1	6	2	60
HCP132M-8	3	5.3	750	91.5	≥0.95	3.1	6	2	75
HCP160M-8	4	7.1	750	92.3	≥0.95	3.1	6	2	102
HCP160M-8	5.5	9.7	750	93.1	≥0.95	3.1	6	2	110
HCP160L-8	7.5	13.2	750	93.7	≥0.95	3.1	6	2	131
HCP180M-8	11	19.2	750	94.2	≥0.95	3	6.6	2	175
HCP200L-8	15	26	750	94.7	≥0.95	3	6.6	2	235
HCP225S-8	18.5	32	750	95.1	≥0.95	3	6.6	1.8	280
HCP225M-8	22	38	750	95.4	≥0.95	3	6.6	1.8	300
HCP250M-8	30	51.5	750	95.6	≥0.95	2.9	6.6	1.8	380
HCP280S-8	37	63.5	750	95.8	≥0.95	2.9	6.6	1.8	480
HCP280M-8	45	77	750	95.8	≥0.95	2.9	6.6	1.8	560
HCP315S-8	55	94.5	750	95.9	≥0.95	2.8	6.4	1.6	920
HCP315M-8	75	128.5	750	96	≥0.95	2.8	6.4	1.6	990
HCP315L-8	90	153	750	96	≥0.95	2.8	6.4	1.6	1083
HCP315L-8	110	188	750	96	≥0.95	2.8	6.4	1.6	1180
HCP315L-8	132	226	750	96.1	≥0.95	2.8	6.4	1.6	1250
HCP355M-8	160	275	750	96.1	≥0.95	2.8	6.4	1.6	1910
HCP355M-8	180	308	750	96.1	≥0.95	2.8	6.4	1.6	2020
HCP355L-8	200	343	750	96.1	≥0.95	2.8	6.4	1.6	2080
HCP355L-8	250	428	750	96.1	≥0.95	2.8	6.4	1.6	2150
HCP355L-8	280	480	750	96.1	≥0.95	2.8	6.4	1.6	2230
HCP355L-8	315	540	750	96.1	≥0.95	2.8	6.4	1.6	2300

Applications:

Permanent Magnet Synchronous Motor: Revolutionizing Energy Efficiency

Brand Name: HC

Model Number: JN-HCP-5

Place of Origin: China

Certification: ISO9001 CCC CE

Minimum Order Quantity: 50PCS

Price: Negotiable

Packaging Details: By Sea Pallet / By Air Carton / By Express Packaging

Delivery Time: 25 Days

Payment Terms: L/C, T/T

Supply Ability: 30K PCS/Month

Introduction

The Permanent Magnet Synchronous Motor (PMSM), also known as Internal Permanent Magnet Motor (IPM), is a highly efficient and energy-saving motor that is widely used in various industrial and commercial applications. One of the most popular and reliable brands in the market is HC's JN-HCP-5 PMSM.

Application

The JN-HCP-5 PMSM is suitable for a wide range of applications, including:

Industrial machinery and equipment
Electric vehicles
Refrigeration systems
Pump and fan systems
HVAC systems
Compressors
Conveyor systems

Product Features

The JN-HCP-5 PMSM boasts the following features:

High Efficiency: With its internal permanent magnets, this motor has a higher efficiency compared to traditional motors, resulting in significant energy savings.
Low Noise: The use of permanent magnets reduces the noise level of the motor, making it ideal for applications that require quiet operation.
Stable Performance: The advanced design and high-quality components ensure stable and reliable performance, even in harsh industrial environments.

Product Specifications

Speed Adjust: The motor can be easily controlled and adjusted using a Variable Frequency Drive (VFD).
Insulation Level: The motor has a high insulation level of F, ensuring safety and reliability.
Rate Output: The JN-HCP-5 PMSM has a rated output of 1.1~11KW, making it suitable for a wide range of applications.
Phase: It is a three-phase motor, providing a balanced and stable power supply.
Main Parts: The main parts of the motor are imported, ensuring high quality and reliable performance.

Benefits

The JN-HCP-5 PMSM offers numerous benefits, including:

Significant energy savings
Reduced operating costs
Lower maintenance costs
Longer lifespan
Improved efficiency and productivity

Conclusion

The JN-HCP-5 PMSM from HC is a top-of-the-line product that offers high efficiency, energy savings, low noise, and stable performance. Its advanced design, high-quality components, and reliable performance make it the perfect choice for a wide range of industrial and commercial applications. With HC's commitment to quality and customer satisfaction, the JN-HCP-5 PMSM is the ideal choice for revolutionizing energy efficiency in your business.

Customization:

HC Permanent Magnet Synchronous Motor Customization Service

Brand Name: HC

Model Number: JN-HCP-5

Place of Origin: CHINA

Certification: ISO9001 CCC CE

Minimum Order Quantity: 50PCS

Price: Negotiable

Packaging Details: By Sea Pallet /By Air Carton / By Express Packaging

Delivery Time: 25 Days

Payment Terms: L/C,T/T

Supply Ability: 30K PCS/Month

Phase: Three-phase, Three Phase

Rate Output: 1.1~11KW

Efficiency Level: IE4

Cooling Type: IC01

Protection Grade: IP54/IP55

Key Features:

Magnetic Synchronous Motor
Multiphase Permanent Magnet Motor
High Efficiency Motor
Customized Packaging and Delivery
Reliable Quality
Fast Delivery
Competitive Price

Packing and Shipping:

Packaging and Shipping for Permanent Magnet Synchronous Motor

Our Permanent Magnet Synchronous Motor is carefully packaged to ensure safe delivery to our customers. The packaging materials used are sturdy and designed to protect the motor from any damage during transportation.

Each motor is packed in a strong and durable cardboard box, with additional cushioning materials to prevent any movement or impact during shipping. The box is then sealed securely to protect the motor from dust, moisture, and other external factors.

For international shipping, our motors are packaged and shipped in compliance with all necessary regulations and requirements. This ensures that our products reach our customers in a timely and efficient manner, without any delays or complications.

Our shipping partners are carefully selected to ensure reliable and on-time delivery of our Permanent Magnet Synchronous Motors. We work closely with them to track the shipment and provide updates to our customers regarding the status of their order.

Upon delivery, our motors are accompanied by all necessary documents, including a product manual, warranty card, and any other required certifications. This ensures that our customers have all the information they need to properly install and use our motors.

We take great care in packaging and shipping our Permanent Magnet Synchronous Motors to ensure that they reach our customers in perfect condition. We are committed to providing the highest quality products and services to our customers, and this extends to our packaging and shipping processes as well.

FAQ:

Q: What is the brand name of this product?
A: The brand name of this product is HC.
Q: What is the model number of this product?
A: The model number of this product is JN-HCP-5.
Q: Where is this product made?
A: This product is made in China.
Q: Is this product certified?
A: Yes, this product is certified with ISO9001, CCC, and CE.
Q: What is the minimum order quantity for this product?
A: The minimum order quantity for this product is 50 pieces.

Product Tags:


*From:	Your email address is incorrect!
*To:	Jiangsu Jiuneng Electromechanical Technology Co., Ltd.
*Subject:	Subject is empty!
*Message:	For the best results, we recommend including the following details: -Self introduction -Required specifications -Inquire about price/MOQ Characters Remaining: (0/3000) Please enter 20 to 3000 characters to contact this supplier!
