0.1mm Tolerance Rare Earth Cobalt Magnet Perfect Choice For Magnetic Separators

Ask Lasest Price
Brand Name :	JN
Model Number :	JN-CO-2
Certification :	ISO9001
Price :	Negotiable
Delivery Time :	25 Days
Payment Terms :	L/C,T/T
Supply Ability :	500K PCS/Month

Add to Cart

Product Details
Company Profile

0.1mm Tolerance Rare Earth Cobalt Magnet Perfect Choice For Magnetic Separators

0.1mm Tolerance Rare Earth Cobalt Magnet Perfect Choice for Magnetic Separators

JN's SmCo Magnets have a wide range of applications and are suitable for various scenarios, thanks to their unique properties and shape options. Some of the common applications and scenarios for our SmCo Magnets include:

Bar SmCo Magnet - Ideal for use in motors, generators, and loudspeakers.
Disc SmCo Magnet - Perfect for sensors, magnetic couplings, and magnetic bearings.
Cylinder SmCo Magnet - Suitable for aerospace and military equipment.
Ring SmCo Magnet - Used in MRI machines, magnetic separators, and magnetic chucks.
Arc SmCo Magnet - Great for high-speed motors, magnetic pumps, and magnetic couplings.
Segment SmCo Magnet - Commonly used in magnetic levitation systems, magnetic switches, and magnetic clamps.
No matter what your industry or specific application may be, JN's SmCo Magnets can provide the high performance you need.

Technical Parameters:

Advantages	High Temperature Stability, High Magnetic Strength, Corrosion Resistance
Curie Temperature	700-800°C
Magnetic Properties	High Magnetic Energy Product, High Coercive Force, High Remanence
Demagnetization Resistance	Excellent
Applications	Motors, Sensors, Magnetic Couplings, Magnetic Separators, Etc.
Magnetization	Multipolar Or So
Shape	Disc, Cylinder, Block, Ring, Arc, Segment, Etc.
Color	Brown, Black
Tolerance	0.1mm
Property	Isotropic And Anisotropic Is Avaible

Grade		Residual Induction			Coercive Force		Intrinsic Coercive Force		Max. Energy Product		Max. Working Temperature
		Br			Hcb		Hcj		(BH)max		Tw
		kGs		T	kOe	KA/m	kOe	KA/m	MGOe	KJ/m³	℃
SmCo5	SC16		8.1-8.5	0.81-0.85	7.8-8.3	620-660	15-23	1194-1830	14-16	110-127	250
	SC18		8.5-9.0	0.85-0.90	8.3-8.8	660-700	15-23	1194-1830	16-18	127-143	250
	SC20		9.0-9.4	0.90-0.94	8.5-9.1	676-725	15-23	1194-1830	19-21	150-167	250
	SC22		9.2-9.6	0.92-0.96	8.9-9.4	710-748	15-23	1194-1830	20-22	160-175	250
	SC24		9.6-10.0	0.96- 1.00	9.2-9.7	730-770	15-23	1194-1830	22-24	175-190	250
Sm2Co17	SCS22		9.3-9.7	0.93-0.97	8.5-9.3	676-740	>18	>1433	20-23	160-183	350
	SCS24		9.5-10.2	0.95- 1.02	8.7-9.6	692-764	>18	>1433	22-24	175-191	350
	SCS24H		9.5-10.2	0.95- 1.02	8.7-9.6	692-764	>25	>1990	22-24	175-191	350
	SCS26M		10.2-10.5	1.02- 1.05	8.5-9.8	676-780	12-18	955-1433	24-26	191-207	350
	SCS26		10.2-10.5	1.02- 1.05	9.4-10.0	748-796	>18	>1433	24-26	191-207	350
	SCS26H		10.2-10.5	1.02- 1.05	9.4-10.0	748-796	>25	>1990	24-26	191-207	350
	SCS28M		10.3-10.8	1.03- 1.08	8.5-10.0	676-796	12-18	955-1433	26-28	207-223	350
	SCS28		10.3-10.8	1.03- 1.08	9.5-10.2	796-812	>18	>1433	26-28	207-223	350
	SCS28H		10.3-10.8	1.03- 1.08	9.5-10.2	796-812	>25	>1990	26-28	207-223	350
	SCS30M		10.8-11.0	1.08- 1.10	8.5-10.5	676-835	12-18	955-1433	28-30	223-239	350
	SCS30		10.8-11.0	1.08- 1.10	9.9-10.5	788-835	>18	>1433	28-30	223-239	350
	SCS30H		10.8-11.0	1.08- 1.10	9.9-10.5	788-835	>25	>1990	28-30	223-239	350
	SCS32M		11.0-11.3	1.10-1.13	8.5-10.7	676-852	12-18	955-1433	29-32	231-255	350
	SCS32		11.0-11.3	1.10-1.13	10.2-10.8	812-860	>18	>1433	29-32	231-255	350
	SCS32H		11.0-11.3	1.10-1.13	10.2-10.8	812-860	>25	>1990	29-32	231-255	350
	SCS35		11.6-12.0	1.16-1.20	10.9-11.4	868-908	>18	>1433	32-35	255-278	350
Low Temp Coeff Sm2Co17	SCL18LT		8.4-8.9	0.84-0.89	7.9-8.4	629-668	>18	>1433	17-19	135-151	350
	SCL20LT		8.9-9.4	0.89-0.94	8.3-8.9	660-708	>18	>1433	19-21	151-167	350
	SCL22LT		9.4-9.8	0.94-0.98	8.7-9.3	692-740	>18	>1433	21-23	167-183	350
High Temp Resistance Sm2Co17	SCG24		9.9-10.4	0.99- 1.04	9.3-9.9	740-788	>23	>1830	23-25	183-199	400
	SCG22		9.4-9.9	0.94-0.99	8.8-9.4	700-748	>23	>1830	21-23	167-183	450
	SCG20		8.9-9.4	0.89-0.94	8.3-8.9	660-708	>23	>1830	19-21	151-167	500
