Jiangsu Jiuneng Electromechanical Technology Co., Ltd.
4 Years
| Ask Lasest Price | |
| Brand Name : | JN |
| Model Number : | JN-AL-4 |
| Certification : | ISO9001 |
| Price : | Negotiable |
| Delivery Time : | 25 Days |
| Payment Terms : | L/C,T/T |
| Supply Ability : | 2000K PCS/Month |
Alnico magnets are an essential component in many industrial and commercial applications due to their exceptional magnetic properties and high working temperature. These magnets are made from a special combination of aluminum, nickel, and cobalt, known as magnetic alloys of aluminum-nickel-cobalt, or alnico for short.
With a maximum working temperature of 450-550°C, these high temperature alnico magnets are designed to withstand extreme heat without losing their magnetic strength. This makes them ideal for use in industries such as aerospace, automotive, and oil and gas, where high temperatures are a constant factor.
One of the key advantages of alnico magnets is their high coercivity, which refers to their ability to resist demagnetization. This makes them ideal for use in applications where a strong and stable magnetic field is required, such as in motors, generators, and sensors.
In addition, alnico magnets also have high remanence, which means they retain a high level of magnetization even after the external magnetic field is removed. This property, combined with their high coercivity, makes alnico magnets a popular choice for permanent magnet applications.
The density of alnico magnets ranges from 7.3-7.5 G/cm3, making them relatively lightweight compared to other magnet materials. This makes them suitable for use in applications where weight is a critical factor, such as in motors and speakers.
At our company, we take great pride in producing high-quality alnico magnets with a tolerance of ±0.05mm. This ensures that our magnets meet the required specifications and provide consistent performance in every application.
In conclusion, alnico magnets are a versatile and reliable choice for a wide range of industries and applications. With their high working temperature, magnetic properties, and precision manufacturing, our permanent alnico magnetic materials are the perfect solution for your magnetic needs.
| Properties | Values |
|---|---|
| Applications | Sensors, Motors, Generators, Loudspeakers, Magnetic Separators, Etc. |
| Maximum Working Temperature | 450-550°C |
| Shape | Bar, Disc, Ring, Block, Cylinder |
| Density | 7.3-7.5 G/cm3 |
| Tolerance | ±0.05mm |
| Max Working Temperature | 550°C |
| Magnetic Properties | High Coercivity, High Remanence, High Energy Product |
| Grade | Alnico 2, Alnico 5, Alnico 8 |
| Material | Alnico (Magnetic Alloys of Aluminum-Nickel-Cobalt) |
| Manufacturing Process | Casting Or Sintering |
| Industrial Use | Industrial Alnico Magnets |
| Grade | MMPA | Residual Induction | Coercive Force | Max. Energy Product | Max. Working Temperature | ||
| Br | Hcb | (BH)max | Tw | ||||
| kGs | T | kOe | KA/M | MGOe KJ/m³ | ℃ | ||
| LNl0 | ALNICO3 | 6.0 | 0.60 | 0.50 | 40 | 1.25 10 | 550 |
| LNG 10 | 6.0 | 0.60 | 0.55 | 44 | 1.25 10 | 550 | |
| LNG12 | ALNICO2 | 7.0 | 0.70 | 0.55 | 44 | 1.50 12 | 550 |
| LNG 13 | 6.8 | 0.68 | 0.60 | 48 | 1.63 13 | 550 | |
| LNG16 | ALNICO4 | 8.0 | 0.80 | 0.60 | 48 | 2.00 16 | 550 |
| LNG18 | 9.0 | 0.90 | 0.60 | 48 | 2.25 18 | 550 | |
| LNG37 | ALNICOS | 12.0 | 1.20 | 0.60 | 48 | 4.63 37 | 550 |
| LNG40 | 12.3 | 1.23 | 0.60 | 48 | 5.00 40 | 550 | |
| LNG44 | 12.5 | 1.25 | 0.65 | 52 | 5.50 44 | 550 | |
| LNG48 | ALNICOSDG | 12.8 | 1.28 | 0.70 | 56 | 6.00 48 | 550 |
| LNG52 | 13.0 | 1.30 | 0.70 | 56 | 6.50 52 | 550 | |
| LNG56 | ALNICO5—7 | 13.0 | 1.30 | 0.72 | 58 | 7.00 56 | 550 |
| LNG60 | 13.3 | 1.33 | 0.75 | 60 | 7.50 60 | 550 | |
| LNGT28 | ALNICO6 | 10.0 | 1.00 | 0.70 | 56 | 3.50 28 | 550 |
| LNGT30 | 11.0 | 1.10 | 0.70 | 56 | 3.75 30 | 550 | |
| LNGT18 | ALNICO8 | 5.8 | 0.58 | 1.00 | 80 | 2.25 18 | 550 |
| LNGT32 | 8.0 | 0.80 | 1.zs | 100 | 4.00 32 | 550 | |
| LNGT38 | 8.0 | 0.80 | 1.38 | 110 | 4.75 38 | 550 | |
| LNGT44 | 8.5 | 0.85 | 1.45 | lls | 5.50 44 | 550 | |
| LNGT48 | ALNICO8HE | 9.0 | 0.90 | 1.50 | 120 | 6.00 48 | 550 |
| LNGT60 | ALNICO9 | 9.0 | 0.90 | 1.38 | 110 | 7.50 60 | 550 |
| LNGT72 | 10.5 | 1.05 | 1.40 | 112 | 9.00 72 | 550 | |
| LNGT80 | 10.8 | 1.08 | 1.50 | 120 | 10.00 80 | 550 | |
| LNGT88 | 11.0 | 1.10 | 1.45 | 115 | 11.00 88 | 550 | |
| LNGT96 | 11.5 | 1.15 | 1.48 | 118 | 12.00 96 | 550 | |
| LNGT36J | ALNICO8HC | 7.0 | 0.70 | 1.75 | 140 | 4.50 36 | 550 |
| LNGT40J | 7.0 | 0.70 | 1.75 | 140 | 5.00 40 | 550 | |
| LNGT44J | 7.5 | 0.75 | 1.75 | 140 | 5.50 44 | 550 | |
| LNGT48J | 8.0 | 0.80 | 1.82 | 145 | 6.00 48 | 550 | |
| LNGT52J | 8.5 | 0.85 | 1.75 | 140 | 6.50 52 | 550 | |
| Grade | MMPA | Residual Induction | Coercive Force | Max. Energy Product | Max. Working Temperature | ||
| Br | Hcb | (BH)max | Tw | ||||
| kGs | T | kOe | KA/M | MGOe KJ/m³ | ℃ | ||
| FLN8 | S.ALNICO3 | 5.0 | 0.50 | 0.50 | 40 | 1.00 8 | 450 |
| FLNG12 | S.ALNICO2 | 6.5 | 0.65 | 0.60 | 48 | 1.50 12 | 450 |
| FLNGT18 | S.ALNICO7 | 6.0 | 0.60 | 1.13 | 90 | 2.20 18 | 450 |
| FLNG34 | S.ALNICO5 | 12.0 | 1.20 | 0.60 | 48 | 4.25 34 | 450 |
| FLNGT28 | S.ALNICO6 | 10.5 | 1.05 | 0.70 | 56 | 3.50 28 | 450 |
| FLNGT38 | S.ALNICO8 | 8.0 | 0.80 | 1.50 | 120 | 4.75 38 | 450 |
| FLNGT42 | S.ALNICO8 | 8.8 | 0.88 | 1.50 | 120 | 5.25 42 | 450 |
| FLNGT33J | S.ALNICO8HC | 7.0 | 0.70 | 1.75 | 140 | 4.13 33 | 450 |
Brand Name: JN
Model Number: JN-AL-3
Place of Origin: CHINA
Certification: ISO9001
Minimum Order Quantity: 1000PCS
Price: Negotiable
Packaging Details: By Sea Pallet /By Air Carton / By Express Packaging
Delivery Time: 25 Days
Payment Terms: L/C,T/T
Supply Ability: 2000K PCS/Month
Maximum Working Temperature: 450-550°C
Material: Alnico
Tolerance: ±0.05mm
Composite: AlNiCo Magnet
Manufacturing Process: Casting Or Sintering
Alnico Magnet, known as one of the most powerful permanent magnetic materials, is widely used in various industrial applications. With its unique magnetic properties, high temperature resistance, and strong magnetic force, it has become a preferred choice for many industries in need of reliable and durable magnetic solutions.
Alnico magnets are widely used in various industries, including but not limited to:
Alnico magnets are made of a combination of aluminum, nickel, and cobalt, along with other elements such as copper and iron. This composition gives them unique magnetic properties, making them one of the strongest permanent magnets available in the market. They have a high coercivity, which means they can resist being demagnetized, making them suitable for applications where strong magnetic fields are required.
Unlike other permanent magnets, Alnico magnets have a maximum working temperature of 450-550°C, making them suitable for high-temperature applications. This makes them an ideal choice for industries that require magnetic solutions in extreme temperature environments, such as motors and generators.
Alnico magnets can be manufactured with precise tolerances of ±0.05mm, making them suitable for applications that require high precision and accuracy. They can also be customized into various shapes and sizes, making them suitable for a wide range of industrial applications.
Alnico magnets are known for their durability and reliability. They have a long-lasting magnetic stability, ensuring consistent performance even in harsh environments. This makes them a cost-effective solution for industries that require long-lasting and reliable magnetic materials.
Alnico magnets are made from environmentally friendly materials and do not contain any harmful substances. This makes them a safe and sustainable choice for industries that prioritize environmental consciousness.
Our Alnico magnets are manufactured in compliance with ISO9001 standards, ensuring high-quality and consistent products. This certification also guarantees that our products meet international standards and are suitable for various industrial applications.
Alnico magnets can be easily installed and integrated into various industrial systems, making them a convenient solution for industries that require quick and efficient installation.
Overall, Alnico magnets, with their unique properties and wide range of industrial applications, are a powerful solution for many industries in need of reliable and durable magnetic materials. Choose JN Alnico Magnet for your next industrial project and experience the benefits of our high-quality and cost-effective products.
Brand Name: JN
Model Number: JN-AL-3
Place of Origin: CHINA
Certification: ISO9001
Minimum Order Quantity: 1000PCS
Price: Negotiable
Packaging Details: By Sea Pallet /By Air Carton / By Express Packaging
Delivery Time: 25 Days
Payment Terms: L/C,T/T
Supply Ability: 2000K PCS/Month
Composite: AlNiCo Magnet
Maximum Working Temperature: 450-550°C
Density: 7.3-7.5 G/cm3
Material: Alnico
Manufacturing Process: Casting Or Sintering
The Alnico Magnet will be packaged according to industry standards to ensure safe transport and delivery to our customers. The packaging materials used will be sturdy and durable to withstand the rigors of shipping. The magnet will be carefully wrapped and protected to prevent any damage during transportation.
We understand the importance of protecting the magnet from external factors such as moisture and impact. Therefore, the package will be sealed and waterproofed to prevent any potential damage.
We offer various shipping options to cater to the needs of our customers. Our standard shipping method is through reliable and reputable courier services, such as DHL, UPS, and FedEx. These services provide timely and secure delivery of our products to the designated address.
For larger orders, we also offer sea or air freight options for more cost-effective shipping. Our team will work closely with our customers to determine the best shipping method based on their location and order quantity.
We pride ourselves on our efficient shipping process and aim to deliver the Alnico Magnet to our customers as quickly as possible. We also provide tracking information for our customers to monitor the status of their shipment.
For any special packaging or shipping requirements, please contact our customer service team for assistance. We are committed to providing the best packaging and shipping solutions for our customers.
|
|
